| สถานที่กำเนิด: | จีน |
| ชื่อแบรนด์: | BRANDO |
| ได้รับการรับรอง: | None |
| หมายเลขรุ่น: | VX2360-04 |
| จำนวนสั่งซื้อขั้นต่ำ: | 1 ชิ้น |
|---|---|
| ราคา: | สามารถต่อรองได้ |
| รายละเอียดการบรรจุ: | กล่องภายใน, กล่อง, พาเลท |
| เวลาการส่งมอบ: | การเจรจาต่อรอง |
| เงื่อนไขการชำระเงิน: | T/T, เวสเทิร์นยูเนี่ยน, MoneyGram |
| สามารถในการผลิต: | 100,000 ชิ้นต่อเดือน |
| ขนาดพอร์ต: | 1/2'' | ขนาดปาก: | 13 มม. |
|---|---|---|---|
| การดำเนินการ: | ไดอะแฟรมยกโดยตรง | ช่วงความดัน: | 0 ถึง 1 MPa |
| วัสดุตัวเครื่อง: | ทองเหลือง | แรงดันไฟฟ้า: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| อุณหภูมิปานกลาง: | NBR: -5 ถึง +80°C, EPDM: -5 ถึง +120°C, FKM: -10 ถึง +150°C | วัสดุซีล: | NBR, EPDM, FKM |
| เน้น: | SMC Solenoid Valve VX2360-04,SMC Solenoid Valve1/2'',SMC VX2360-04 Solenoid Valve |
||
VX2360-04 1/2'' SMC Type Brass Solenoid Valve for Water Air 220V 110V 24V
Product Features:
1. Working Media: Air, Water, Gas, Liquid, Steam, etc
2. Working Pressure: 0 to 10 bar
3. Medium Temperature: NBR: -5 to +80℃, EPDM: -5 to +120℃, FKM: -10 to +150℃
4. Port Size: 3/8'', 1/2''
5. Orifice Size: 10mm, 13mm
6. Body Material: Brass
7. Seal Material: NBR, EPDM, FKM
8. Function: 2 Way Normally Closed
9. Operation: Direct Acting
10. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Technical Data:
|
BRANDO Model
|
VX2260-03
|
VX2360-03
|
VX2360-04
|
|
Ref No
|
VX2120-10
|
VX2130-10
|
VX2130-15
|
|
Orifice Size
|
10mm
|
13mm
|
13mm
|
|
Port Size
|
3/8''
|
3/8''
|
1/2''
|
|
Medium
|
Water, Air, Gas, Liquid, Steam, etc
|
||
|
Operation
|
Direct Acting
|
||
|
Function
|
2 Way Normally Closed
|
||
|
Body Material
|
Brass
|
||
|
Seal Material
|
NBR, EPDM, FKM
|
||
|
Medium Temperature
|
NBR: -5 to +80℃
EPDM: -5 to +120℃ FKM: -10 to +150℃ |
||
|
Working Pressure
|
0 to 10 bar
|
||
|
Voltage
|
12VDC, 24VDC, 24VAC, 110VAC, 220VAC, other voltages can be customzied
|
||
Main Dimension:
![]()
|
BRANDO Model
|
Port
|
A
|
B
|
C
|
|
VX2260-03
(VX2120-10)
|
3/8''
|
40
|
50
|
80
|
|
VX2360-03
(VX2130-10) |
3/8''
|
40
|
50
|
80
|
|
VX2360-04
(VX2130-15)
|
1/2''
|
48
|
66
|
110
|
Our Production:
![]()
More Pneumatic Products for you to choose:
| 2/2 Way Pneumatic Valves | 3/2 Way Pneumatic Valves | 5/2 Way Pneumatic Valves | 5/3 Way Pneumatic Valves |
| Namur Solenoid Valves | Air Pilot Valves | Pneumatic Cylinders | Silencers and Fittings |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
