| สถานที่กำเนิด: | หนิงโป จีน |
| ชื่อแบรนด์: | BRANDO |
| ได้รับการรับรอง: | None |
| หมายเลขรุ่น: | BB14542505 |
| จำนวนสั่งซื้อขั้นต่ำ: | 200 |
|---|---|
| ราคา: | สามารถต่อรองได้ |
| รายละเอียดการบรรจุ: | กล่องภายใน, กล่อง, พาเลท |
| เวลาการส่งมอบ: | การเจรจาต่อรอง |
| เงื่อนไขการชำระเงิน: | T/T, เพย์พาล, เวสเทิร์นยูเนี่ยน |
| สามารถในการผลิต: | 100,000 ชิ้นต่อเดือน |
| ชื่อสินค้า: | ขดลวดโซลินอยด์วาล์ว | แรงดันไฟฟ้า: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
|---|---|---|---|
| พลัง: | 18VA,28VA,14W,20W | ตัวเชื่อมต่อ: | DIN43650A |
| เน้น: | Solenoid Valve Coil 0545 00.1-00/5802 220v,0545 00.1-00/5802 220V Solenoid Valve Coil,0545 Solenoid Valve Coil |
||
0545 00.1-00/5802 220V Solenoid Valve Coil 0545 for PU Series Valve
This solenoid coil is same with Nass Magnet solenoid coil 0545, which is popularly used in Shako solenoid valves, like PU220A, PU225A, SPU225A, PU225S series. Coil Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC. Coil Power: 18VA, 28VA, 14W, 20W. The solenoid coil is integral in the operation of a solenoid valve. It is what converts the electric current into a magnetic field which in turn allows the operation of the solenoid valve.
Dimension & Data of 0545 Solenoid Coil, Armature:
![]()
|
BRANDO Model
|
BB14542505
|
|
Ordering Code
|
0545
|
|
Voltage
|
220VAC, 110VAC,
24VDC, 12VDC
|
|
Power
|
18VA, 28VA, 14W, 20W
|
|
Other voltage and power can be customized
|
|
|
Connector
|
DIN43650A
|
![]()
|
BRANDO Model
|
BAPC214548001
|
|
Function
|
2 Way Normally Closed
|
|
Tube Material
|
Stainless Steel
|
|
Seal Material
|
NBR, EPDM, FKM
|
Ordering Code of 0545 Solenoid Coil:
| Code No | Voltages | Frequency(Hz) |
Power (W)
|
Power (VA) |
| 113-030-0123 | 24VDC | 4,1 | ||
| 113-030-0144 | 24VAC | 50 | 8,8 | |
| 113-030-0144 | 24VAC | 60 | 7,6 | |
| 113-030-0128 | 220VAC | 50 | 9,0 | |
| 113-030-0128 | 240VAC | 60 | 9,2 | |
| 113-030-0142 | 230VAC | 50 | 8,8 | |
| 113-030-0142 | 230VAC | 60 | 7,6 | |
| 113-030-0121 | 220VAC | 50 | 14,0 | |
| 113-030-0124 | 24VDC | - | 7,9 | |
| 113-030-0135 | 24VAC | 50 | 14,0 | |
| 113-030-0135 | 24VAC | 60 | 12,0 | |
| 113-030-0279 | 110VAC | 50 | 13,9 | |
| 113-030-0279 | 110VAC | 60 | 12,2 | |
| 113-030-0125 | 24VDC | - | 11,9 | |
| 113-030-0129 | 24VAC | 50 | 21,0 | |
| 113-030-0129 | 24VAC | 60 | 18,0 | |
| 113-030-0126 | 110VAC | 50 | 21,5 | |
| 113-030-0141 | 230VAC | 50 | 22,0 | |
| 113-030-0141 | 230VAC | 60 | 19,0 | |
| 113-030-0120 | 12VDC | - | 17,5 | |
| 113-030-0127 | 24VAC | 50 | 25,0 | |
| 113-030-0132 | 24VDC | - | 18,5 | |
| 113-030-0120 | 36VAC | 50 | 25,0 | |
| 113-030-0137 | 110VAC | 50 | 27,5 | |
| 113-030-0140 | 110VAC | 60 | 26,5 | |
| 113-030-0137 | 120VAC | 60 | 28,0 | |
| 113-030-0133 | 220VAC | 50 | 25,5 | |
| 113-030-0122 | 220VAC | 50 | 22,0 | |
| 113-030-0138 | 230VAC | 50 | 25,5 | |
| 113-030-0133 | 240VAC | 60 | 25,0 | |
| 113-030-0138 | 240VAC | 60 | 27,0 |
Video of 0545 Solenoid Coil:
BRANDO Solenoid Valve Coils Production Video:
More Solenoid Valves for you to choose:
| PU220A Series | PU225A Series |
| SPU225A Series | PU225S Series |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
