| สถานที่กำเนิด: | จีน |
| ชื่อแบรนด์: | Ningbo BRANDO |
| ได้รับการรับรอง: | None |
| หมายเลขรุ่น: | M50 |
| จำนวนสั่งซื้อขั้นต่ำ: | 1 ชุด |
|---|---|
| ราคา: | สามารถต่อรองได้ |
| รายละเอียดการบรรจุ: | กล่องภายใน, กล่อง, พาเลท |
| เวลาการส่งมอบ: | 7 วันทำการ |
| เงื่อนไขการชำระเงิน: | T/T, เวสเทิร์นยูเนี่ยน, เพย์พาล |
| สามารถในการผลิต: | 100,000 ชิ้นต่อเดือน |
| ชื่อสินค้า: | พัลส์วาล์วไดอะแฟรม | วัสดุไดอะแฟรม: | NBR, VITON |
|---|---|---|---|
| ติดตั้งพอร์ตวาล์วพัลส์: | 2'' | แบบจำลองวาล์วชีพจรที่ติดตั้ง: | FP50, FM50, FP55, FM55, SQP50, SQM50, SQP55, SQM55, SQP60, SQM60, SQP65, SQM65 |
| 1 ชุด: | ไดอะแฟรม M50 1 ชิ้น, ไดอะแฟรม M25 1 ชิ้น, สปริง 2 ชิ้น | ||
| เน้น: | TKITM50 Turbo Diaphragm,Turbo M50 Diaphragm,Turbo Membrane Kit M50 |
||
M50 2'' Turbo Diaphragm Repair Kit for FP55 SQP55 SQP65 Pulse Valve TKISM50
M50 Diaphragm (Membrane) for Turbo pulse valve FP50, FM50, FP55, FM55, SQP50, SQM50, SQP55, SQM55, SQP60, SQM60, SQP65, SQM65; NBR material is standard, working temperature range is -5 to +80 ℃; VITON material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse jet valves are indirect operated solenoid valves especially designed for dust collector systems. When the solenoid is energized, trapped air above a diaphragm is quickly exhausted causing a high pressure difference across the diaphragm. Thereby the diaphragm is suddenly opened. When the solenoid is de-energized, air escapes through a hole to the chamber above the diaphragm which balances the pressure and instantly closes the valve.
Ordering Code of Diaphragm For Turbo Pulse Valve:
Dimension of M50 Diaphragm:
![]()
Video of M50 + M25 Diaphragm:
Pictures of Pulse Valve Membrane Production:
![]()
More Turbo Type Pulse Jet Valve for you to choose:
| Threaded Type | Submerged Type | Valve Diaphragm |
| Solenoid Coil | Solenoid Armature | Pulse Controller |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
