Diaphragm Repair Kit For 2'' DMF-Z-50S DMF-Y-50S DMF-T-50S SBFEC Type Old Version Pulse Jet Valve

Diaphragm Repair Kit For 2'' DMF-Z-50S DMF-Y-50S DMF-T-50S SBFEC Type Old Version Pulse Jet Valve

Diaphragm (Membrane) for Old Version 2'' BFEC pulse valve DMF-Z-50S, DMF-Y-50S, DMF-T-50S; NBR material is standard, working temperature range is -5 to +80 ℃; Viton material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse valves are operated by integral solenoid pilot operator. When the valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pilot operated valve is de - energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the valve.

Ordering Number of Diaphragm For SBFEC Pulse Valve:

Main Dimension of LD50 Diaphragm For Old Version BFEC Pulse Valve:

Video of LD50 Membrane For Old Version BFEC Pulse Valve:

Pictures of Pulse Valve Diaphragm Production:
