Pilot Solenoid Valve Diaphragm For SBFEC Types Dmf Pulse Valve

Pilot Solenoid Valve Diaphragm For SBFEC Types Dmf Pulse Valve

Pilot Diaphragm Position in Pulse Valve:

1, Solenoid Coil
2, Hole for pressure releasing
3, Pilot diaphragm
4, Back cavity of diaphragm
5, Main diaphragm
6, Front chamber of diaphragm
7, Releasing hole

Pulse valve diaphragm is a kind of part to control the fluid go through or stop in the valve, and the diaphragm should often work with many times in one day. So the diaphragm should be with good performance of flexibility and and sealing. Obviously, the material of pulse valve diaphragm directly relating to the working life and effect of the diaphragm and even the pulse valve. In other words, the quality of pulse valve diaphragm can lead to the stability of the pulse valve working performance, and also directly connect to the using cost of the dust collector quipment.

Advantage of Pulse Valve Pilot Diaphragm:

Our company specially design the diaphragm to match the working environment such as normall temperature, high temperature and low temperature and let the diaphragm can work correctly together with other operating parts in the valve then to ensure the pulse valve can blow the compressed clean air and ensure the pulse valve can stable work under all kinds of severe work environment.

Pulse Valve Pilot Dimensions:

Application of the Pulse Valve Diaphragm:

We also supply complete pulse valve and other spare parts of the pulse valve, highly welcome your any enquiry, and we will offer you price quickly.
